GPS-911 Real-Time Personal Tracking Kit


  • High sensitivity GPS: -159 dBm

  • Omni-direction GPS

  • SOS function

  • Geo-fence function

  • Phone conversation

  • Built-in speaker, MIC & battery

  • Configurable transmission interval

  • Sound monitor & personal tracking

  • Compact, portable and good looking plastic housing

  • Quad-band (850/900/1800/1900 MHz) GSM, SMS & GPRS


A DIY tracking software for you to set up a mini Fleet Management System at office or home for tracking over Maps up to 100 people/vehicles (the standard version delivered with each device), or 101-500 vehicles (extra payment required).

  • GPS Data Logger Function new

When GSM Network is not available, the GPS data will be stored in the memory upto 17500 records. Once the device receives GSM signal again, the logged data will be sent back to server automatically.

  • Support Tow Fixed IP Addresses -only available from GoPass

Through GPRS sending GPS data to 2 fixed IP addresses networked by computers.

  • GEO-fence (Park) Function - guarding vehicle against theft

The tracker will alert you by sending a SMS message to your mobile/PDA, when someone moves the car or the asset without permission over a preset distance. It is recommended to set the geo-fence range over 200 meters.

  • A-GPS Function - supporting indoor positioning

Assisted-GPS is only application for Tele-communication System Suppliers.

  • Bi-Direction Phone Conversation Function

You can have a phone conversation by making phone call to GPS-911, and vice versa. When you get an incoming call, there will be a voice prompt, and then press the “Pick-Up/ Hang-Up” button to start the conversation. You can also dial out to the preset 2 phone numbers.


  • SOS Emergency Help Call Function

When you presses the SOS button, the device will immediately send a SMS short-message to the preset phone number.


  • GPS Position Tracking Function

The report method can be via SMS messages or via GPRS.

  • Sound Monitoring Function

You can monitor the situation inside the vehicle remotely from mobile phone by sending a SMS command to this device without interfering the persons in the car.


  • Other Functions:

    • Send back data based on the preset time internal or based on the driving distance

    • Read the volt data by sending a SMS message

    • Get position data thru phone call

    • Set the timetable to send back data automatically

    • Support Sleep Mode

    • If the speed is slower than defined km/ hour for continuous defined time, the device won't send back data

    • Sound alert when battery is low

Panel Description

Power Charging


A tracking software for you to track over Maps real-time by your own PC; no need to pay for the maps or service charges. It can also keep history records for you to replay afterwards. As to reports, it can provide you mileage/ routes/ idle/ over-speed/ detailed activity and fleet summary reports for management purpose. Besides, GooLocate software supports "Remote Data Server" function. The data received by server can be forwarded to any PC links to the internet for data sharing. It enables you to set up a mini-control center by yourself.   >>Learn More


Other free tracking softwares included

 real-time track over
 navigation map in PC
  track the position by
  mobile phone
  track the position by
  PDA phone




GPS-911(R) Hardware Specifications


80 grams (battery included)


79.50 x 47.50 x 25.00 (mm)


EGSM900: TX880-915MHz, RX 925-960MHz

DCS1800: TX 1710-1785MHz, RX 1805-1880MHz

GSM850: TX824-849MHz, RX 869-894MHz

GSM1900: TX1850-1910MHz, RX 1930-1990MHz

 RF Output Power

EGSM900, GSM850: 33 dBm(2W)

GSM1800, GSM1900: 30 dBm(1W)



 Transmission Speed

Circuit switched 4.8/ 9.6 kbps


-159 dBm


L1, 1575.42mhz



 Position Accuracy

10 meters CEP without SA

 Speed Accuracy

0.1 meters/second, without SA

 Coordinate System


 Hot Start

< 6 Seconds average

 Warm Start

< 38 Seconds average

 Cold Start

< 60 Seconds average


Max. 515meters / second1000 knots


6 Buttons: Answer, Quick Dial * 2, Park, SOS, Power


5 LED: Charging, GPS, GSM, Park, SOS


Mini USB PORT for charge and connect to PC.

 Working Voltage

Rechargeable Li-ion battery3.7V 1000mAh ,5 V Input

 Standby Mode

60 hours

 Operating Mode

8 hours



 Operation Temperature

-20°C to +55°C

 Storage Temperature

-30°C to +70°C


0~95%, non-condensing

Gift Box


>> Parts List
