GPS Receiver

Q: How to test the GPS receiver in PDA to check if it can work properly?



1. Please find the CD delivered with each unit of our GPS receiver, and put it in the CD Drive.

2. Open the CD, you can find "GPS1xx/ GPS2xx Tester" folder; "GPT6xx/ GPT7xx Tester"; and "USB Driver" folder...

3. Open "GPS1xx/ GPS2xx Tester" folder; copy "PDA Tester.exe" to your CF/ SD card, put CF/ SD card back to your PDA.

4. Open "File Managers" - "My Devices" - "SD or CF Card" in PDA, and run "PDA Tester.exe"

5. Click on "SCAN" button to scan the COM port.

6. GPS data strings such as below will be displayed in the window, when the COM port found.
$GPRMC,105437.208,A,2410.4786,N,12038.9185,E,0.00,52.22,110603,,*38
$GPGGA,105438.208,2410.4783,N,12038.9186,E,1,04,4.1,115.5,M,,,,0000*0E
$GPGSA,A,2,18,23,30,05,,,,,,,,,6.7,4.1,5.4*38
$GPGSV,2,1,08,23,76,205,37,30,63,078,36,14,49,348,,18,48,161,35*7F

7. The signal strength and satellite status will be displayed, if the signal is strong enough.

Q: How to test the GPS receiver in PC to check if it can work properly?



1. Please find the CD delivered with each unit of our GPS receiver, and put it in the CD Drive.

2. Open the CD, you can find "GPS1xx/ GPS2xx Tester" folder; "GPT6xx/ GPT7xx Tester";  and "USB Driver" folder...

3. Open "GPS1xx/ GPS2xx Tester" folder; then "PC Tester 1.4A.exe", "GPS 1.4A" testing  program window will be shown up.

4. Select the baud rate (4800 or 9600), set the COM port, and choose the command
"GS 99.0 99.0" or the others for your test; click on "OK" to send command; click on
"ON" bottom to start the tester.

5. GPS data strings such as below will be displayed on the top right
$GPRMC,105437.208,A,2410.4786,N,12038.9185,E,0.00,52.22,110603,,*38
$GPGGA,105438.208,2410.4783,N,12038.9186,E,1,04,4.1,115.5,M,,,,0000*0E
$GPGSA,A,2,18,23,30,05,,,,,,,,,6.7,4.1,5.4*38
$GPGSV,2,1,08,23,76,205,37,30,63,078,36,14,49,348,,18,48,161,35*7F

6. The signal strength and satellite status will be displayed in the left side of the testing  program window.

Q: How to connect the GPS receiver to my PC or Notebook?



If you want to connect our PS/2 GPS receiver to your PC or Notebook, you must get a PS/2-USB converting cable from us, and plug the GPS receiver to the USB Port (not PS/2 port for keyboard/ mouse) of your computer - AFTER you have installed the driver for the converting cable. Please make the following installation & setting, before you connect GPS201 + PS2-USB converting cable to the USB port of your computer.

1. Find the CD delivered with each unit of our GPS receiver, and put it in the CD Drive.
2. Open the CD, you can find "GPS1xx/ GPS2xx Tester" folder; "USB Driver" folder...
3. Open "USB Driver" folder; then run & install "USB GPS Driver.exe" to your PC

If you want to know at what COM port the USB cable is connected, please check it as follows:
a). right click "My Computer"
b). select "Management" (G)
c). left click "Devices Manager"
d). un-fold "COM & LPT Port"
e). find out the port for "Prolific USB to Serial COM Port"



Q: Why my GPS receiver can not communicate with my computer?

1. Make sure the GPS Baud rate is set correctly (4800 or 9600).
2. Set GPS NMEA to 0183B. M
3. Set COM port to 4800 baud, 8 bits per second, no parity, one stop bit.
4. Disable or remove any conflicting software from the COM port.



Q: Why my GPS receiver can not track the satellites?



1. GPS receiver can work only under open sky; it can not receive GPS signal indoors.

2. Check the initial position, time and date shown in the GPS display, make sure they  are correct.

3. Initialization can take up to 10 minutes with a clear view of the sky.

Q: Why my GPS receiver needs long time to track the satellites?


It is possibly because the GPS microwave is too feeble. The influence of the satellites microwave on GPS reception is occasionally non-predicable. Different time/ different place, the microwave’s intensity will be different.

Q: Can my GPS receiver work under bad weather?



GPS works 24 hours a day, anywhere in the world. It will be not affected by the bad weather.





Q: What kind of e-map I should use for my GPS navigation?


Generally speaking, our GPS products are compatible with the e-map/ navigation software which support NMEA 0183 and WGS84. Please choose the navigation e-map accordingly.
